I35 Prisma - Integrated Amplifier / DAC / Streamer

I35 Prisma

I35 Prisma integrated amplifier is the latest iteration of Primare’s now iconic 30 Series integrated amplifiers and is the first to use the new UFPD 2 power system, a radical reworking of Primare’s award-winning UFPD all-analog Class-D technology.

Technology

Providing 150 watts at 8 ohms of absolutely linear UFPD 2 amplification across the entire audible bandwidth, the I35 Prisma delivers naturally fast, clean and agile sound with an unprecedented ability to bring music to life.

In addition to balanced analog inputs, the I35 Prisma includes a DM35 full-featured DAC stage enabling up to PCM 384kHz/24bit and DSD 256 conversion, as well as Prisma connectivity and control technology.

Prisma



I35 Prisma features Prisma, Primare’s new whole-home, high-fidelity control and connectivity solution. Prisma provides multi-room/multi-zone connectivity and control for playback of stored and streamed media, wired or wireless, all managed from any mobile device through a dedicated system control app. In addition to Bluetooth, AirPlay, and Spotify Connect, Prisma features Chromecast built-in, a unique streaming portal allowing effortless direct connection to hundreds of streaming applications for the best possible performance and user experience.

Key features:



UFPD 2 Power

2 x 150W 8 ohms / 2 x 300 4 ohms

XLR
2 x stereo pair analog output
RCA
3 x stereo pair analog input
RCA
1 x stereo pair analog output
RCA
1 x stereo pair analog PRE output
C25 remote
IR system control
IR input
3.5 mm in/out
12V Trigger
3.5 mm in/out



I15 Prisma - Integrated Amplifier / DAC / Streamer

I15 Prisma

I15 Prisma continues a Primare tradition of delivering astonishing performance from compact and elegant devices for easy installation into virtually any living environment. With the three-quarter-sized cabinet of I15 Prisma, even greater possibilities open up for providing the highest quality music performance and access to any and every room in the house.

Technology



I15 Prisma integrated amplifier is a compact, full-featured system control and power center, providing 60 watts of power per channel, digital to analog conversion with up to PCM 384kHz and DSD128 capabilities, as well as complete digital media access and system management by way of the Prisma connectivity and control technology.

Prisma



I15 Prisma features Prisma, Primare’s new whole-home, high-fidelity control and connectivity solution. Prisma provides multi-room/multi-zone connectivity and control for playback of stored and streamed media, wired or wireless, all managed from any mobile device through a dedicated system control app. In addition to Bluetooth, AirPlay, and Spotify Connect, Prisma features Chromecast built-in, a unique streaming portal allowing effortless direct connection to hundreds of streaming applications for the best possible performance and user experience.

Primare i35 Integrated Amplifier



PRE60 - Preamplifier / DAC

The PRE60 is a supremely sophisticated system control center that effortlessly brings the ever-expanding world of music to your system in all its richness and variety. Due to Primare’s careful attention to detail, whether the source is analogue or digital, the sound of the PRE60 is unfailingly accurate and convincing: truer to the recording – truer to life.



The goal was simple for the 60 Series – to build the company’s most thoroughly modern and revealing products yet, all while retaining Primare’s inherently musical sound. The 60 Series is a resounding statement and the next step in Primare’s evolution in creating products for which every aspect of design and implementation has been carefully considered and tested.

Entirely designed and hand built in Sweden, the PRE60 preamplifier and A60 amplifier are the culmination of all that Primare has learned in over three decades of producing components of exemplary quality and performance.



The PRE60’s integrated DAC/media board offers virtually every possible option for digital playback of the highest resolution, be it streamed or stored media; even allowing for instantaneous connection of handheld devices. In designing this third-generation media board, Primare has carefully tailored the filtering to reveal every bit of musical information from every digital source.

For easy system setup and operation, the OLED display on the PRE60 provides critical system information in a crisp and clear adaptive presentation when using the system remote.

The Primare App takes your control of the PRE60 to the next level, allowing you to operate the system from your favorite handheld device – including playing streaming services, stored digital media, and thousands of Internet radio stations.

Bluetooth® wireless technology further adds to the ease of exploring, sharing, and enjoying music by allowing for instant connection and playback from enabled mobile devices.

RS232
outboard system control port
Prisma
control and connectivity
USB-A
1 digital input
Ethernet
x 2
WiFi
AirPlay
Bluetooth
Chromecast built-in
Spotify Connect
Dimensions

430 x 420 x 106 mm with buttons and connectors
Weight
11 kg
Finishes - black or titanium

AVAILABLE IN 2 ADDITIONAL VERSIONS
I35 DAC

The I35 DAC adds the DM35 digital analog conversion module to the I35. Prisma technology can be added as a plug-in module at a later date.
I35
The I35 is an all analog version of the I35 Prisma, featuring UFPD 2 power output and balanced analog inputs. The DM35 digital to analog conversion and Prisma modules can be added at a later date.

DAC
AKM AK4497 PCM / DSD

Toslink
4 x digital input
RCA
2 x digital input
RCA
1 x digital output

USB-B
1 x digital input

PRIMARE

Key features:



Power

2 x 65W 8 ohms / 2 x 130 4 ohms
RCA
1 x stereo pair analog input
RCA
1 x stereo pair analog output
3.5mm
1 x stereo analog/digital
C25 remote
IR system control
IR input
3.5 mm in/out
12V Trigger
3.5 mm in/out

RS232
outboard system control port
Prisma
control and connectivity
USB-A
x 1
Ethernet
x 2
WiFi
AirPlay
Bluetooth
Chromecast built-in
Spotify Connect
Dimensions

350 x 329 x 73 mm with buttons and connectors
Weight
6.4 kg
Finishes - black or titanium

DAC
AKM AK4497 PCM / DSD

Toslink
3 x digital input
RCA
1 x digital output

USB-B
1 x digital input

Key features:



XLR
2 x stereo pair analog input


RCA
4 x stereo pair analog inputs


XLR
2 x stereo pair analog PRE outputs


RCA
2 x stereo pair analog PRE outputs


RCA
1 x stereo pair analog REC output


IR control
C24 system remote


IR control
3.5mm input/output


RS232
outboard system control port


12V trigger
1 x 3.5mm input/output

Dimensions
350 x 329 x 73 mm with buttons and connectors


Weight
6.4 kg


Finishes - black or titanium

RS232
outboard system control port
DAC

Crystal

RCA
1 x digital input

USB-B
1 x digital input

RCA
1 x digital output
Ethernet
x 1

Control Apps
Primare APP and AIR
WiFi
AirPlay
Bluetooth
Chromecast built-in
Spotify Connect



A60 - Amplifier

The A60 employs the latest version of Primare’s groundbreaking UFPD (Ultra Fast Power Device) amplification module in a balanced configuration of four discrete amplifiers – two per channel. With this seventh generation of the UFPD, Primare has realised its fullest potential, taking complete advantage of its capacity to provide instantaneous current delivery and extremely low distortion, resulting in a naturally fast, clean, and agile sound.



The goal was simple for the 60 Series – to build the company’s most thoroughly modern and revealing products yet, all while retaining Primare’s inherently musical sound. The 60 Series is a resounding statement and the next step in Primare’s evolution in creating products for which every aspect of design and implementation has been carefully considered and tested.

Entirely designed and hand built in Sweden, the PRE60 preamplifier and A60 amplifier are the culmination of all that Primare has learned in over three decades of producing components of exemplary quality and performance.

Powering the UFPD modules is an equally unique power supply utilising Primare’s Active PFC (Power Factor Correction) technology. So efficient is this technology that it allows for virtually unlimited power delivery to the amp modules without draining power from or injecting noise into the line, ensuring that any system integrating the A60 will deliver the ultimate in precision and impact.

Key features:



UFPD power
2x250W 8 ohms, 2x500W 4 ohm


XLR
1 x stereo pair analog inputs


RCA
1 x stereo pair analog inputs


RS232
outboard system control port

12V trigger
1 x 3.5mm input/output


Dimensions (WxDxH)
430 x 385 x 142mm


Weight
12.5 Kg


Finish
two-tone black and titanium

Primare PRE60 & A60 Stack
