TRI ART AUDIO

P-Series MINI TOWER

​

• Full Range Speaker

  • 1 X Super Tweeter (18kHz – 150kHz)

  • 4 X Natural Colour Paper Cone Drivers

    • 2 X Full-Range Emitters

    • 2 X Md-Bass / 250 hz First Order X-Over

• Spl 86.5 dB

• Pwr 20w Nom.

• 4.0 Ohm

• 5-Way binding posts

• Resonance Pressure Release Hole

• Horn Loaded Transmission Line

• 6″ Wide X 39″ High X 12″ Deep

• Bamboo constraint laminate

• Packed with natural sheep’s wool and wired with solid core copper cable.

• ​Aluminum Sub Platter with Steel Shaft

• Stands Sold Separately



P-series Mini Towers


MSRP $ 2,310 (Pair)



P-series Mini Tower Block Stands

MSRP $ 535 (Pair)







5 - Open   Open Baffle System

​

Rated Impedance :  8 Ohm

Sensitivity :  92 dB (1W/1m) - conservatively rated

Frequency range:  27 – 150'000 Hz (+/- 3dB)

Recommended Amplifier rating (tube amps):

• 12 - 75 W at 8 Ohm

Recommended amplifier rating (SS amps):

• 25 - 150 W at 8 Ohm



2 inputs :
Input 1 :

• 20watts

• 8" full range

• 1" fabric dome tweeter 13,000hz and up

• Super Tweeter 18,000 to 150,000Hz

Input 2 :

• Up to 150watts

• 2 x 15" woofer



Optional crossover:

• 2 inputs

• 3 outputs (including a set .5 meter jumper cables with banana plugs)

  • Output 1 (full range)

    • 100watt Solen attenuator

    • 47ohm resistor

    • 100hrz single solen cap filter

  • Output 2 (bass)

    • Single open air inductor filter 100hz

  • Ouput 3 (subbass)

    • Single open air inductor filter 50hz

All Inputs and outputs are 5-way binding posts

General Series Specifications



Design

Open Baffle

Amplification

Possibility to passively or actively bi-amp

Materials

• Main drivers all paper with accordion style surround

• Drivers mounted with stainless bolts and brass acorn nuts

• 3 ply Bamboo Constraint Baffle

• Finished with hemp oil and beeswax rub

• Wiring is jewelery grade smelted copper single strand

• 3 bronze leveling spikes with brass locknut

• Optional external passive crossover

• Aluminum stand - MRSP $250 - optional

5 - Open

3-Way +1

​

$ 5,900   / Pair

with Stands & Tri-Art BB

Crossover Inductors

​

$ 5,250   / Pair

No Crossover

 for use w/Active X-over

​

+ $150 Shipping

​

West Coast Shipping surcharge :

$125

4 - Open   Open Baffle System

​

Rated Impedance :  8 Ohm

Sensitivity :  93 dB (1W/1m) - conservatively rated

Frequency range:  35 – 150'000 Hz (+/- 3dB)

Recommended Amplifier rating (tube amps):

• 12 - 75 W at 8 Ohm

Recommended amplifier rating (SS amps):

• 25 - 150 W at 8 Ohm



2 inputs :
Input 1 :

• 20watts

• 8" full range

• 1" fabric dome tweeter 13,000hz and up

• Super Tweeter 18,000 to 150,000Hz

Input 2 :

• Up to 150watts

• 1 x 15" woofer



Optional crossover:

• 2 inputs

• 3 outputs

• Including set of .5 meter jumper cables w/ banana plugs

  • Output 1 (full range)

    • 100watt Solen attenuator

    • 47ohm resistor

    • 100hrz single solen cap filter

  • Output 2 (bass)

    • Single open air inductor filter 100hz

All Inputs and outputs are 5-way binding posts

General Series Specifications



Design

Open Baffle

Amplification

Possibility to passively or actively bi-amp

Materials

• Main drivers all paper with accordion style surround

• Drivers mounted with stainless bolts and brass acorn nuts

• 3 ply Bamboo Constraint Baffle

• Finished with hemp oil and beeswax rub

• Wiring is jewelery grade smelted copper single strand

• 3 bronze leveling spikes with brass locknut

• Optional external passive crossover

4 - Open

3-Way +1

​

$ 4,350   / Pair

with Stands & Tri-Art BB

Crossover Inductors

​

$ 3,900   / Pair

No Crossover

 for use w/Active X-over

​

+ $150 Shipping

​

West Coast Shipping surcharge :

$100

3 - Open   Open Baffle System

​

Rated Impedance :  8 Ohm

Sensitivity :  92 dB (1W/1m) - conservative

Frequency range:  45 – 150'000 Hz (+/- 3dB)

Recommended Amplifier rating (tube amps):

• 12 - 75 W at 8 Ohm

Recommended amplifier rating (SS amps):

• 25 - 150 W at 8 Ohm



2 inputs :
Input 1 :

• 20watts

• 8" full range

• 1" fabric dome tweeter 13,000hz and up

• Super Tweeter 18,000 to 150,000Hz

Input 2 :

• Up to 100watts

• 1 x 8" woofer

Optional crossover:

• 2 inputs

• 3 outputs

• Including set of .5 meter jumper cables w/ banana plugs

  • Output 1 (full range)

    • 100watt Solen attenuator

    • 47ohm resistor

    • 100hrz single solen cap filter

  • Output 2 (bass)

    • Single open air inductor filter 100hz

All Inputs and outputs are 5-way binding posts

3 - Open

2-Way +1

​

$ 2,890   / Pair

​

+ $125 Shipping

​

West Coast Shipping surcharge :

$75

2 - Open   Open Baffle Bass Extension System

​

Rated Impedance :  8 Ohm

Sensitivity :  92 dB (1W/1m) - conservative

Frequency range:  25 – 100 Hz (+/- 3dB)

Recommended Amplifier rating (tube amps):

• 12 - 75 W at 8 Ohm

Recommended amplifier rating (SS amps):

• 25 - 150 W at 8 Ohm



2 inputs :
Input 1 :

• up to 150 watts

• 1 x 15" full range

Input 2 :

• Up to 150watts

• 1 x 15" woofer

Optional crossover:

• 2 inputs

• 3 outputs

• Including set of .5 meter jumper cables w/ banana plugs

  • Output 1 (full range)

    • 100watt Solen attenuator

    • 47ohm resistor

    • 100hrz single solen cap filter

  • Output 2 (bass)

    • Single open air inductor filter 100hz

All Inputs and outputs are 5-way binding posts

2 - Open

2-Way +1

​

$ 3,650   / Pair

with Stands & Crossover

​

+ $150 Shipping

​

West Coast Shipping surcharge :

$100
